High wear resistant ceramic pulley lagging which installed onsite.

Ceramic Pulley Lagging, Ceramic Lagging Sheet, Ceramic Rubber Lagging

Pulley Ceramic Lagging, Ceramic lining, Ceramic Rubber Sheet

Conveyor belt skirt rubber / skirtboard

Conveyor belt skirt rubber / skirt board

Application:

Used for sealing between the belt and guide chute, the skirt board with dual layer structure, which installed under the belt conveyor guide chute by a quick clamp device.

Advantages:

1. Dual Sealing: Inner can isolate material spillover, outer can suppress dust in the sky.

2. Polyurethane wear resistant layer, long service life and protect the belt

3. Quick clamp device, easy installation.

Specification:

Thickness: 15~25 mm

Width: 150~300 mm

Length: Custom

Working temperature: -30 C ~ 70 C

Conveyor Accessories Manufacturer / Material Handling Equipment Parts

Conveyor Accessories Manufacturer / Material Handling Equipment Parts

1. Conveyor Pulley Lagging : Slide lag, ceramic rubber lagging, diamond lagging sheet

2. Impact bed & impact bar

3. Conveyor belt repair materials

4. Conveyor belt cleaner system

5. Polyurethane rubber roller

6. Silicone rubber roller

7. Conveyor belt skirt rubber / skirt board

8. Shock absorber / rubber buffer / rubber bumper / rubber damper

9. Rubber seals

Choose Slide lag-Replaceable Pulley Lagging for Conveyor System

Slide lag-Replaceable Pulley Lagging for Conveyor System

1. Application: Coal mine, steel, grain, cementing, feed, port, metallurgy, machinery, etc.

2. Four core advantages:

a.) Low cost: Just replace the damaged rubber pads, non-whole part replaced.

b.) Easy installation:Welded by retainer, safe and firmness, easy operation

c.) Fast maintenance: Pulley/drum without remove, installation on site

d.) Long service life: Superior rubber material, high wear resistant

3. Four core features:

a.) High wear resistant:  Rubber pads are made of high wear resistant rubber material.

b.) Fraction performance: The diamond pattern and groove can help belt running, increasing friction and traction

c.) Adaptable: According to different requirements, types of coal resistant, high temperature resistant, anti-static and flame retardant are available

d.) Custom service: Custom is available according to different size & spec. of pulleys.

Size:

1. Standard length: 1830mm, 2000mm (  It's can be cut according to pulley length )

2. Standard width: 138mm

3. Starndard thickness: 15mm --22 mm

High wear resistant ceramic lagging pulley for extremely working conditions.

Ceramic rubber lagging pulley for extremely working conditions.

Ceramic embossed CN backed natural rubber lagging provides extremely high positive drive between the pulley and the conveyor belt under conditions beyond the capacity of normal rubber lagging.

Application:

1. Pulley lagging under extreme environment
2. Drive pulley
3. Tail pulley
4. Suitable for delivering wet, sticky, mud and high wear materials
5. Suitable for high strength and high tension conveyor systems.


Ceramic wear resistant:        < 60mm ( Testing: grind 30 minutes under RPM 200)
Ceramic tile hardness:          Mohs 9
Heat resistant temperature:  < 85
Rubber Elongation:                400 %
Rubber hardness:                  60+/- 5 Shore A
Ceramic tile size:                   20*20*8mm
